4CH 720P HDD SD Card 3G WIFI G-Sensor Vehicle MDVR

1. H.264 video compression, multi code stream.

2. Support 4CH 720P HD real-time video inputs. Also, support 4CH analog cameras inputs or compound inputs for 2CH HD cameras and 2CH analog cameras.

3. 1CH VGA output is optional.

4. With exclusive pre-allocated type vehicle file system technology, it solved the file fragmentation problems which caused by overwrite, SD card data loss and SD card couldn’t be found, keep the data completed and stable.

5. 8-36V wide voltage power supply, super low power consumption. With overload/ under voltage/ short-circuit/ reversing protection, support all vehicles.

6. Support a 2T 2.5 -inch HDD and 1 256G SD card storage

7. With watchdog abnormal restart protection function, it can better protect the machine and video.

8. Delayed video recording functions when vehicle is shut down (time settings can be up to 24 hours).

9. Various video recording modes to meet different demands, such as automatic recording, manual recording, alarm recording, etc.

10. Support 4CH alarming inputs and 1CH independent alarm input.

11. Optional for 1CH RS232 Serial port or 1CH RS485 extension.

12. Support GPS/G-Sensor.

13. Support remote operation and monitoring by 3G.

14. Support Wi-Fi and automatic data download.

15. Support ministry of communications agreement, support SMS remote configuration and equipment control.

16. Support voice broadcast, intercom and text schedule dispatch.

17. Support fuel sensor, temperature sensor, POS, LED advertising screen.

18. Support shockproof aviation connector, easy to plug or pull out, with best quality and best price, stable and reliable.

19. With full enclosed lock design, it can prevent the man-made sabotage effectively; Support mouse operating.

20. Support all vehicles, including bus, taxi, truck, school bus, etc.

Specifications:

Operating System Linux
Language English, Chinese or Customized language.
Video Compression H.264
OSD Support  for time, date, vehicle ID, image, etc.
GUI OSD Interface

Can external connect to LCD and set the system specifications

by remote

Videoand Recording Video Input

4CH 720P AHD/Analog/Compound video input, aviation connector,

1.0Vp-p, 75Ω

Video Output

1CH Compound video output with optional VGA output, 1.0Vp-p, 75Ω.

Support 1CH full screen and 4CH division.

Preview

Single/4CH Pictures Preview, support full screen of event trigger or

back view of car reversing

Recording Resolution Support 720P/D1/HD1/CIF, support at maximum 4 Channels 720P
Recording Quality Optional Recording for Grade 0-7. 0 is the highest and 7 is the lowest.
Video Rate

PAL:100 fps,CCIR625line,50 scenes

NTSC:120 fps,CCIR525line,60 scenes

CIF:256Kbps - 1.5Mbps,8 grades image quality for optional

HD1:600Kbps - 2.5Mbps,8 grades image quality for optional

D1:800Kbps - 3Mbps,8 grades image quality for optional

720P:800Kbps - 4Mbps,8 grades image quality for optional

Recording Mode

Default automatic video recording, support ignition video recording,

schedule video recording, alarm video recording, etc

Audio Audio Input 4CH Aviation connector inputs
Audio Output 1CH Aviation connector output, Output level:1V - 2V
Compression format G.726, Speed for 8KB/s
Alarm Input 4CH level alarm inputs
Alarm Output 1CH level signal output
Communication Interface Optional for 1CH RS232 or 1CH RS485
Wireless Transmission

Support built-in 3G/4G wireless transmission, WCDMA, CDMA2000.Support

expansion built-in/external WIFI transmission, compatible with GPRS, EDGE

Location /G-sensor

Support built-in GPS/BD module, built-in G-sensor, can analysis

and playback

for vehicle driving route
Video Storage Storage Support a 2T 2.5 -inch HDD and 1 256G SD card storage
Upgrade Method Support SD card local upgrade, remote upgrade automatically
File Format H.264 general video format
File System FAT32 exclusive file system
Video Playback Video Search Search recorded video files by recording time and recording method
Playback

Support at max 4 channel synchronous playback, suspend,

forward, backward

Support 2/4/8/16 times speed forward or backward
Security Management

User Password or administrator password management,

support screen locked

Expansion functions TTS Voice broadcast Support TTS voice broadcast
Series port expansion

Support external equipment connecting for advertising screen,

PTZ control, fuel sensor, etc

Power and Consumption Power Management

Self-adaptive wide voltage input, with protect functions for overload,

undervoltage, short circuit, reversing connection, etc

Support time setting startup/shutdown, delayed power off function
Input Voltage DC:+8V - +36V
Output Voltage +12V-1.5A,+5V-1.5A
Power-off Protection

UPS technology to protect all recorded information automatically and

make sure the files undamaged in case of sudden power off.

Consumption Normal working < 14W, standby < 0.5W
Working environment Temperature -20℃ - +70℃
Humidity 20% - 80%
SD Card Type Series Dimension 180*200*60MM
Weight 2.7KG
